The 1515 LED strip light series features SMD 1515 LEDs—miniature LEDs measuring just 1.5mm x 1.5mm—offering ultra-slim design, tight spacing, and precise light output. Ideal for discreet lighting in compact profiles or fine-edge illumination, this series delivers excellent color consistency and smooth, dot-free light even at close range.
Key Features:
- LED Type: SMD 1515 – micro-sized for ultra-thin applications
- LED Density: Up to 300 LEDs/m for seamless linear lighting
- High CRI: Options with CRI >90 for accurate color rendering
- Power Consumption: Ranges from 4.8W to 14.4W/m, depending on density
- Lumen Output: Up to 1000–1400 lm/m (white CCT versions)
- Cuttable: 25mm (24V)
- Dimmable: Compatible with PWM and low-voltage dimming systems
- PCB Width: Narrow strip widths (5mm to 8mm), suitable for slim channels
- Ingress Protection: Available in IP20 / IP65 / IP67
- Thermal Efficiency: Efficient even at high densities due to copper PCB
Applications:
- Display case and jewelry lighting
- Linear backlighting for signage or logos
- Ultra-slim profile or edge-lit installations
- Decorative and accent lighting in tight spaces
- Architectural detail lighting (niches, coves, trims)
Certifications & Reliability:
- Certifications: CE, RoHS (UL upon request)
- Lifespan: 30,000–50,000 hours
- General Warranty: 2–3 years (depending on configuration)
